Thermal Radiation FlamePropagation Tester NFP92-501

Brand Name:	GOLD
Model Number:	GD-NFP92-501
MOQ:	1 set
Price:	USD 6000-8000
Delivery Time:	25 working days
Payment Terms:	L/C,Western Union,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Product:

Thermal Radiation FlamePropagation Tester

Standard:

NFP92-501

Pressure Range Of Gas Regulating Valve:

<0.1MPa

Dimension:

1600*650*1450mm

Weight:

About 78kg

Power:

220 V, 10 Amps, 10A

Packaging Details:

Plywood case

Supply Ability:

10 sets per month

Highlight:

Thermal Radiation Flame Propagation Tester

Smoke Density Tester NFP92-501

Flame Propagation Tester with warranty

Product Description

Thermal Radiation Flame Propagation Tester NFP92-501

The Thermal Radiation Flame Propagation Tester provides performance evaluation of rigid and elastic materials with thicknesses greater than 5 mm. Developed according to the French building materials and railway vehicle flame retardant test standard NF P92-501, this equipment applies 30KW/m² heat radiation to samples, potentially causing volatile gas release and combustion. The system monitors flame spread patterns and collects combustion data to evaluate material exothermic properties.

Key Features

Stainless steel test box with flame-resistant inner walls and transparent observation window
Stainless steel tubular air inlet device with filter to shield indoor pollution sources
45-degree test stand with stainless steel indicator rule for flame spread distance calculation
Thermal radiation device providing 30KW/m² thermal radiant flux
Power controller for radiation output adjustment and radiant flux control
Panel display showing thermal radiation device operating power values
Changming small flame device for easy ignition of upper and lower burners
Quarter rotary plug device for convenient burner cutoff and flame ignition
Upper and lower stainless steel burners for igniting volatile flammable gases
Needle valve control for upper and lower burner flame height with flame height gauge
Top and air inlet thermocouples for real-time temperature monitoring
Standard test software for automatic calculation of flame index and combustion index
Built-in test reporting with data output and printing capabilities

Technical Specifications

Width	1600mm
Depth	650mm
Height	1450mm
Weight	Approximately 78kg
Radiator Rated Power	500W
Power Meter Accuracy	0.5
Pressure Range of Gas Regulating Valve	<0.1MPa
Power Requirements	220V, 10 Amps, 10A

About Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.

Since 2008, Gold has developed 70 kinds of fire testing instruments and served numerous industries including building materials, aviation, rails, IMO, wire & cable, and safety protection. Our mission is to provide reliable products that meet customer requirements for testing, R&D, and quality control. We maintain high-quality standards in niche markets and aim to minimize the gap between Chinese local products and imported products. We operate with trust, honesty, and responsibility, making quality and service our key competitive advantages.
