| Brand Name: | GOLD |
| Model Number: | GD-ASTM C518 |
| MOQ: | 1 set |
| Price: | USD9000-9500/set |
| Delivery Time: | 30 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram |
| Thermal Conductivity Range | 0.0001~1W/mk (accurate to 0.1mW/mk) 0.001~300W/mk (auto-ranging) |
| Measurement Accuracy | 1% |
| Sample Size | 50×50~150×150mm, 150×150~300×300mm (standard) Custom sizes: 600×600mm, 800×600mm available |
| Sample Thickness | Maximum 50mm |
| Material Compatibility | Solid materials and powdered materials |
| Measurement Time | 15-20 minutes |
| Hot Surface Temperature | Room temperature~99.9°C (standard) Options: Room temperature~299.9°C, Room temperature~499.9°C |
| Cold Surface Temperature | 0~99.9°C (standard) Options: -10~99.9°C, custom lower temperatures available |
| Sample Clamping Pressure | 0~1000N, resolution 0.1N |
| Thickness Measurement | 0~50mm, resolution 1μm |
| Power Supply | 220V, 50Hz, 1KW |
| Main Unit | 550 × 450 × 1500 mm, 100 kg |
| Precision Water Tank | 300 × 350 × 530 mm, 35 kg |
